- 美国JEWELL ASMP-200角加速度计传感器原装正品
详细信息
品牌:美国JEWELL 型号:ASMP-200 加工定制:否 制作工艺:集成 输出信号:模拟型 材料:金属 材料物理性质:导体 材料晶体结构:单晶 防护等级:1 线性度:1 %F.S 迟滞:1 %F.S 重复性:1 %F.S 灵敏度:1 分辨率:1 美国JEWELL ASMP-2 ASM 角加速度计传感器原装正品
ASMP系列角加速度传感器
型号:ASMP-200、ASMP-500、ASMP-1000
Input Ranges From ±200.0 to ±1,000 With Miniaturization, High Accuracy, and Ruggedness
The Jewell ASM Series Angular Accelerometer are configured specifically to yield a combination of miniaturization, high accuracy, and ruggedness.
The ASM Series has been designed to minimize thermal errors associated with outdoor applications.
The Jewell ASM Series is the highest accuracy sensor of it's class in the world today..特点和优点:
• Bandwidth to 200 Hz
• 1.05" Cube Housing Size
• ± 15 Standard Input Voltage
• Aerospace Quality and Reliability应用:
• Fatigue Monitoring
• Oil Well Drilling
• Flight Control Systems
• Automotive Angular Accelerometer Testing
• Antenna Stabilization
• Autopilot System Testing
• Optical System Stabilization
• Missile Orientation
• Fire Control规格:
性能指标
测量范围(rad/sec²):
±200
±500
±1000
测量轴(x-y):
1
1
1
满量程输出(FRO),VDC±1%:
±5.0
±5.0
±5.0
非线性,(%)FROmax:
0.50
0.20
0.10
灵敏度(volts/rad/sec²):
0.025
0.010
0.005
灵敏度随温度误差(PPM/℃)max:
180
180
180
带宽(-3db),Hz:
70
100
120
零位偏置(rad/sec²):
1.0
4.0
4.0
零位偏置随温度误差rad/sec²/°Cmax:
0.4
0.4
0.4
分辨率(rad/sec²)max:
0.004
0.010
0.020
电气指标
输入电压(VDC):
±15to±10
输入电流(mA):
10
输出阻抗,(ohms)
4000
噪声(mV)rms,max:
5.0
环境指标
工作温度:
-55to+95℃
存储温度:
-65to+105℃
振动:
100 grms
密封
MIL-STD-202, Method 112,IP65
重量
57 g
-
