美国Jewell LCF-196-14.5, LCF-196-30, LCF-196-90双轴倾角计

LCF-196 Biaxial Series Inclinometer

Biaxial Inclinometer is a
±14.5 to ±90 device, with
lower ranges available
with customization.

The Jewell LCF 196 Series is a
high accuracy sensor designed for
applications where high levels of
shock and vibration are present. The

LCF 196 is a two-axis tilt sensor in a
22 mm diameter stainless steel
package.

Features & Benefits
• Very low hysteresis
• Excellent turn on repeatability
• High Accuracy Sensor
• 500g Shock Capability
• IP65 Sealed Housing
• Less > 0.02% Non-linearity
• Bias Temp Sens >50μg/°C
• Small diameter

Applications

• Geophysical Measurement
• Earth Movement Monitoring
• Oil & Gas Well Logging
• Dam Monitoring
• Heavy Construction, Grading
• Ship & Barge Leveling
• Deviation Surveys
• Continuous Casting
• Weapons Platform Leveling
• Data Logging
